    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Ask Lasest Price
    Brand Name : Rigoal
    Model Number : M8 assembly connector
    Certification : CE,RoHS
    Price : negotiable
    Supply Ability : 10000 per week
    Delivery Time : 7-10days
    • Product Details
    • Company Profile

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines


    Product description

    M8 connector is the ideal for environmentally sensitive industrial applications, such as such as sensor, controller, actuator, pressure regulator, stepper motor, driver, and I/O fieldbus,etc.


    Quick details

    1. M8 assembly connector 4pins male gender

    2. Connector locking system is bolted

    3. Termination is solder

    4. Wire gauge(mm) is 0.25mm²

    5. Wire gage(AWG) 24

    6. Cable outlet can be 3,5 - 5,0 mm

    7. Temperature will from -40° to +85°

    8. Contacts 3.4.5.6.8pins avaliable

    9. Contact material CuZn (brass)

    10. Contact plating Au (gold)

    11. Contact body material is PA

    12. Housing material is PA


    Electrical values

    Rated current (40 °C) :4 A

    Rated voltage :60 V

    Rated impulse voltage :1500 V

    Pollution degree :3

    Overvoltage category :III

    Insulating material group :III

    Volume resistivity :≤ 3 mΩ

    EMC compliance :not shielded

    Degree of protection :IP67

    Mechanical operation :> 100 Mating cycles


    Type of ContactFemale Right Angle
    Number of Poles4
    Cable GlandM9.5 x 1
    Coupling NutM8 x 1 Brass With Nickel Plated
    O-RingViton/NBR
    ContactsCopper Alloy


    Product photos

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Assembly Straight 3pin M8 Waterproof Female Sensor Connector For Automation Machines

    Packsging & Shipping

    1.Our general packing: PE bag and PE bag contons. General Carton size:40*30*30cm

    2.Customized according to customer's request


    M8 connector can be used a wide fields like LED, Automation, Sensor, mechanise equipment etc.

    • LED lighting , white light , color light etc

    • Low current equipement

    • Connector be used in narrow environment

    • Communication equipement

    • Lighting harness


    Rigoal-----Your Best Connection!
