    5A 4 Pin Circular Connector Male

    Ask Lasest Price
    Brand Name : Rigoal
    Model Number : UCU
    Certification : CE , Rohs
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100000pcs per day
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    5A 4 Pin Circular Connector Male

    Waterproof Plastic Connector High Power M14 4pins Assembly Male Shielded Connector


    Product description

    ♦ The anti-UV level of the plastic material used on our waterproof connector is F1 or above, which can adapt to the extreme environment.

    As the shield connector, if customer need, we also can do the special processing on the metal to make it can pass the salt spray 720 hours test, which make our connector also exert good function in the extreme environment.

    Our waterproof product series covered from RJ 45,USB,D-SUB, circular connector, power connector, cable gland, socket of hearing aid and vent plug…etc., and their waterproof rating can be chosen from IP65, IP66, IP67, IP68

    the plastic type connector is equivalent to M14/M21 series product

    these connector are also equivalent to Weipu series connector

    CE,Rohs certificate are avaliable

    samples are free for checking


    Quick Details

    Product name:UCU connector

    Gender: male

    Current Rating:5A

    Number of contacts: 4pins

    Mating style: screw

    Back Shell:Circular

    Waterproof Rating:IP68

    Seal for cable OD:Φ3mm~Φ7mm

    Contact resistance:<5mΩ

    Insulation resistance:≥500MΩ at DC500V

    Breakdown voltage: ≥1000v/1minute

    Assembly Style: Field Installable(Solder)


    Material

    Connector body: Flame Retardant Nylon

    Contact:Brass C2680 and C17200 gold plated

    Sealing:EPDM

    Plastic Housing: Engineering Thermoplastic. Flammability Rating UL 94V-0


    Connector sizeUCU connector
    Contacts4pins
    Gendermale
    Contact diameterΦ1x4
    Current Rating5A

    Product Photos

    5A 4 Pin Circular Connector Male5A 4 Pin Circular Connector Male


    FAQ


    Q1. What kind of connectors you could supply?

    A: M8, M12, M16, M23, Industrial waterproof connector, weipu connector, solenoid valve connector etc, also can customized based on buyer's requirements as long as tell us your details


    Q2: How can I get a connector’s sample?

    Sample in stock is free; you just need to pay shipping cost.


    Q3: How long is your delivery time?

    A: Sample is around 5 working days; Mass is 5-15 work days.


    Q4: What’s the connector made of?

    Material ot contact: CuZn

    Contact plating: Au (Gold/gold)

    Material of contact body: PBT (UL 94 V-0)

    Material of housing: CuZn (brass, nickel plated)


    Q5: Is it OK to print my Logo on the product?

    A: Yes, OEM/ODM service is available.
